Efficiency and Longevity

Sequence Centrifugal Pumps are designed and built to meet the special needs of ponds, waterscapes and aquaculture. Buying "quality" really pays. Not only do you get years of dependable service, but you enjoy tremendous savings on your electric bill, every month.

These are the work horses of the industry. They provide tremendous flow rates, with enough pressure (head) to handle the requirements of most  systems with biological filters and moderate height waterfalls. They are also used extensively for the transfer and re-circulation requirements of  filtration systems, water features, streams, fountains and aquaculture.

Product Features

• Less than half the watt draw of comparable submersible pumps
• Ports are 2" FNPT suction and 2" FNPT discharge
• Units are pre-wired with an 8' cord and molded 115 Volt plug
• Housing is molded of high strength, glass filled polypropylene
• Quiet operation
• Dry run resistant mechanical seals
• Stainless steel hardware is standard
• The motors are TEFC, for excellent protection
• Motors are aluminum for added weather resistance
• Rebuildable, industrial grade motors
• Suitable for waterfalls and water courses
• DO NOT SUBMERSE
• These are not suction pumps - a priming pot (sold separately) and a check valve are required
• If your suction height is excessively high, please contact us prior to ordering
• 3-year manufacturer's limited warranty

Product Specifications

	8200SEQ22
HP	1/2
Voltage	115 V
Watts @ 115 V	450
Maximum Flow Rate (GPH)	8280
GPH @ 4 ft.	7500
GPH @ 8 ft.	6720
GPH @ 12 ft.	5760
GPH @ 16 ft.	4680
Maximum Head	22'
Recommended Tubing Diameter	3" (adapters required)
